A custom designed D-shaped post to suit the Pinarello Dogma F12, F10 and F8 series.
The main post is made of carbon fiber using bidirectional and unidirectional fabrics with an studied asymmetrical laminate to achieve the optimum combination of minimum weight and maximum of resistance.
Each seatpost is laminated by hand to achieve a record weight keeping in mind the strength and your safety. To do this, at each point of the seatpost there are a different numbers and arrangements of carbon fiber layers. The layers arrangement is obtained after finite elements analysis and destructive testing.
The totally new designed clamping system for the straight versions is made with two ultralight Dyneema® loops. That makes a very important weight reduction on the head of the seatpost / clamping system. This system is good for all kind of rails, including carbon rails 7*9mm.
Specifications
Post/Cradle Material: Carbon Fibre
Shaft/Barrel Material: 7075 Aluminium
Bolts: Gr5 Titanium
Offset: Zero
Length: 350mm (or Custom)
Diameter: Specific to Dogma F12
Finish: UD Gloss or Matte
Made in Spain
Max Weight Limit (Rider + Luggage)
90kg
Mfr Claimed Weight
100g
Note: Due to the unique construction method, the carbon weave may appear to be slightly un-finished, however there is no impact to stability or durability.
SeatPosts also available for:
Epsilon MTB integrated Handlebar
Ellipse Road Handlebar
Ellipse Gravel Handlebar
Nexum Classic
Nexum Drag
Nexum Drag Gravel
IX4 Stem
IX2 Stem
IX2AL Alloy Stem
IX2AL Alloy Custom Stem
IX4AL Alloy Stem
IX4AL Alloy Custom Stem
Aero XDS X-LAB AD9 Straight
Aero XDS X-LAB Downbraker Offset
Aero Super Six Evo Straight
Aero Super Six Evo Setback
Aero Cannondale LAB71 (straight/offset)
Aero BMC Teammachine (until 2020)
Aero BMC Teammachine 2021
Aero BMC Teammachine 2021, Offset
Aero BMC TwoStroke, Roadmachine 2021
Aero BMC Setback 11.5mm TwoStroke, Roadmachine 2021
Aero BMC Teammachine R01 (Straight/Offset)
Aero Colnago (C64, V3RS, V3,G3, X)
Aero Colnago Seatback 13mm (C64, V3RS, V3, G3, X)
Aero Colnago V5RS (straight/Offset)
Aero Colnago Y1RS (+7,5 straight/-7,5 Offset)
Aero Colnago TT1 (straight/offset)
Aero ENVE Melee (straight, offset)
Aero Pinarello (F10, F12, F8, Prince) Straight
Aero Pinarello Dogma F (straight/offset)
Aero Factor Ostro (Straight/offset)
Aero Factor Ostro Vam 2.0 2024 (Straight/Offset)
Aero S-Works Tarmac SL8 (straight/offset)
Aero S-Works Tarmac SL7
Aero S-Works Tarmac SL6
Aero Cervèlo R5, Caledonia (straight)
Aero Cervèlo Soloist (straight/setback)
Aero Canyon Aeroad (2015-20)
Aero Giant Revolt, TCX
Aero Berria Belador
Aero Berria Belador Sb.15mm
